Lennox Elite series User Manual

28
Wire Harness Diagram
CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous
operation.
ATTENTION: Au moment de l'entretien des commandes, étiquetez tous les fils avant de les débrancher. Des erreurs de cáblage
peuvent entraîner un fonctionnement inadéquat et dangereux.
POWER CORD
SNAP SWITCH
SPEED CONTROL
SWITCH
BLOWER
MALE SPADE 1/4"
FEMALE SPADE 1/4"
RING LUG CRIMP
W
H
T
FEMALE SPADE 1/4"
FEMALE SPADE 1/4"
x3
24"
Remote Thermostat Plug
Wht 5"
BLK 5"
GRN 24"
WHT 5"
BLK 18"
BLK 5"
BLK 16"
FEMALE SPADE 1/4"
MALE SPADE 1/4"
BLK 24"
FEMALE SPADE
1/4"
6ft
Figure 38
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
