SPARE PART LIST
FLEXYII_WSHP-IOM-1307-E - 80 -
Refrigeration
components
Designation Familly Code
Compressor
ZP154KCE
Compressor
4220431T
ZP182 KCE
4220432V
ZP235 KCE
4220433W
INDOOR coil
ID Fbox
Coil
4310442L
ID Gbox
4310443M
ID Hbox
4310472H
OUTDOOR coil
OD Fbox
Coil
4310445P
OD Fbox
4310446R
OD Gbox
4310447T
OD Gbox
4310448V
OD Hbox
4310449W
OD Hbox
4310450X
Expansion valve
Thermostatic expansion valve
TGEL20-19
Refrigeration circuit
4720918E
Thermostatic expansion valve
TGEL20-23
4720912V
Thermostatic expansion valve
TGEL40-31
4720924M
Electronic expansion valve
E3V45
4720928T
Electronic expansion valve
E3V55
4720155H
cable EEV 3M
4720931X
cable EEV 6M
4720156J
Driver EEV
4770717M
Filter Drier
DMB165S
Refrigeration circuit
4720905K
DML165S
4720907M
DML167S
4720908N
Non return valve
NRV16S
Refrigeration circuit
4720002H
4 way valve
STF0715
Refrigeration circuit
4740101N
STF1511
4740104T
STF2506
4740105V
STF3006
4740107X
4 way valve coil
24V 50
4740103R
Pressure switch
HP sensor 4/20mA 45 bar Quick-On
Control
4770212V
BP sensor 0/5V 20 bar Quick On
4770214X
Inox flexible tube
Inox flexible tube 7/8 DN20 600mm
Hoses
4681043P
Inox flexible tube 1 3/8 DN32 800mm
4681044P
Inox flexible tube 1 5/8 DN40 850mm
4681025M
Tigthening ring
D28 428 Pa
Piping
5680573L
D35 535 Pa
5680574M
D40 542 Pa
5680575N
Casing
Designation
Familly
Code
Economiser
Fresh air hood grille Ebox
Sheetmetal
4921086T
Fresh air hood grille Fbox
4921087V
Fresh air hood grille Gbox
4921088W
Lock1/4T
1000-U188-N2+51+990
Fixings
5880163Z
Handle dorr
1091-103-02
5880109W
Handle Outdoor coil
M443/140N
5880160W
Charnieres clips
8576178 SNAP LINE
5880187L
