SIZE A B C D E F G H J K L M N P Q R
F-BOX 85-10 0-12 0 215 8 284 0 200 4 103 0 205 6 274 0 165 0 205 310 800 140 700 133 5 430 593 95
G-BOX 150-170 215 8 353 6 249 3 103 0 205 6 343 6 165 0 410 310 800 140 700 154 0 430 770 95
H-BOX 200-230 215 8 416 5 249 3 103 0 205 6 406 5 255 0 100 310 800 80 800 183 0 430 111 3 95
RETURN ROOFCURB
CAUTION
: An approach ramp must be installed if the
machine installation requirements tell that it's necessary
to reach the main sw itch. This recommendation is valid
for installations in general and in particular for return
and curbs. It’s also valid to reach other parts of the unit:
filters, refrigerant circuit, etc…
SUPPLY AIR
MAIN POWER ENTRY
EXH
AUST
AIR
RET URN AIR
