Lennox FLEXY II Series

IOM – FLEXY II – 1007 – E Page 27
SIZE A B C D E F G H J K L M N
F-BOX 85-10 0-12 0 205 6 200 8 207 2 366 278 3 188 0 70 85 530 700 145 143 2 342
G-BOX 150-170 205 6 249 6 207 2 366 348 0 237 7 70 85 530 700 145 154 0 440
H-BOX 200-230 205 6 249 3 207 2 366 410 6 237 7 70 85 530 800 85 183 0 440
TRANSITION CURB
SUPPLY AIR
MAIN POWER ENTRY
RET URN AIR
All units
