Lennox FLEXY II Series

IOM – FLEXY II – 1007 – E Page 47
Connection HWC F-G-H box
Pipe Internal Diameters (DN)
MAXIMU M WORKING PRESSURE: 8 BARS
MAXIMU M WORKING TE MPERA TURE: 110°C
F085
F100 F120 F150 F170 F200 F230
S 25 25 25 32 32 32 32
H 32 32 32 40 40 40 40
HEATING
: HOT WATER COIL
