Lennox GAH 020S

• 33 •
GAC/GAH 090S-110S-125S
SPXX KGRL
DPXX WFIF
AVUB PHRF
GAC-H_090S_125S_Z
GAC_090S-125S_S_H_Z
Installation manual /eCOMFORT-MIL150E-0916 / 05/2017
1.- GENERAL CHARACTERISTICS
1.9.- DIMENSIONS
STANDARD VERSION
UNIT WITH STANDARD EC FANS (SEAS) OR HIGH PRESSURE EC FANS (HIPF)
All dimensions in mm
All dimensions in mm
5
meters
1,5
meters
1,5
meters
1,5
meters
1,5
meters
Controller connection Ø 29
Victaulic or welded connection Flange connection Flange connection
Controller connection Ø 29
Victaulic or welded connection Flange connection Flange connection
Hydraulic module with single pump Flange connection
Hydraulic module with twin pum Water fi lter (supplied loose)
Rubber anti-vibration mounts Domestic hot water supply : desuperheater
5
meters
1,5
meters
1,5
meters
1,5
meters
1,5
meters
