506053−01 12/10
Page 10
Setting/adjusting indoor temperature from HOME screen (continued)
Indoor settings screen
In addition to making temperature adjustments, you may wish to make
other changes to how your system works. From the HOME screen,
press the screen near press for more.
Figure 16. Accessing Indoor settings screen
The indoor settings screen (figure 17) opens. From this screen, you may
make temperature changes or select other system or fan settings. Use
either of the select buttons to scroll through the available options. With
this screen displayed, pressing either arrow key brings up the set hold
menu as described before (see figure 14).
Fan settings are controlled by the program, however, when changed us-
ing this screen, the program is overridden until the next program event.
The system settings heat & cool option allows the system to automati-
cally switch between heating and cooling as the indoor temperature
changes. The other options, cool only and heat only allow only that por-
tion of the system to satisfy a corresponding cool/heat demand.
system settings
fan settings
heat & cool
cool only
heat only
off
auto
on
circulate
temperature settings
system is
heating
program is ON
current temp
indoor
settings
indoor
humidity
alerts
programs HOME
HELP
select
select
weather
zones
Figure 17. Indoor settings
