Page 25
XC17
COMMUNICATING
STATUS INDICATOR
AIR CONDITIONER CONTROL ONE STAGE
TABLE 3 PROVIDES ADDITIONAL INFORMATION CONCERNING JUMPERS, LOOP, AND CONNECTIONS
FOR THE AIR CONDITIONER CONTROL.
DS12
DS13 and DS15
DS11 and DS14
LED ALERT
CODES
LED ALERT
CODES
E12
E16
E33
TEST PINS
W1
CUT FOR HUMIDITROL APPLICATION
(TWO−STAGE UNITS ONLY)
Figure 11. Control Jumpers, Loop and Terminals (XC17−XXX−230−02 and later)
