Page 24
XC17
Air Conditioner Control (A175) Jumpers and Terminals
AIR CONDITIONER CONTROL ONE STAGE
TABLE 3 PROVIDES ADDITIONAL INFORMATION CONCERNING JUMPERS, LOOP, AND CONNECTIONS
FOR THE AIR CONDITIONER CONTROL.
DS13 and DS15
DS11 and DS14
LED ALERT
CODES
LED ALERT
CODES
CUT FOR HUMIDITROL ENHANCED
DEHUMIDIFICATION ACCESSORY (EDA)
APPLICATIONS.
W1
E12
E16
E33
TEST PINS
Figure 10. Control Jumpers, Loop and Terminals (XC17−XXX−230−01)
