XC17
Model Number Identification
C 17 036− −
Unit Type
C = Air Conditioner
Series
Nominal Cooling Capacity
024 = 2 tons
030 = 2.5 tons
036 = 3 tons
042 = 3.5 tons
048 = 4 tons
060 = 5 tons
Minor Revision Number
230
Voltage
230 = 208/230V−1ph−60hz
Refrigerant Type
X = R−410A
X
−3
Typical Serial Number Identification
8 09 C
Year Code
08 = 2008
09 = 2009
10 = 2010
Month Code
A = January
B = February
C = March
05716
5 (or 6) Digit Unique Number
Location Code
19 = Saltillo, Mexico
58 = Marshalltown, IA
5
Specifications
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XC17−024−230−01 62 7 lbs. 14 oz. 5 26.2
XC17−024−230−02 62 7 lbs. 14 oz. 5 26.2
XC17−024−230−03 62 7 lbs. 14 oz. 5 26.2
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XC17−030−230−01 63 8 lbs. 0 oz. 5 26.2
XC17−030−230−02 63 8 lbs. 0 oz. 5 26.2
XC17−030−230−03 63 8 lbs. 0 oz. 5 26.2
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XC17−036−230−01 70 7 lbs. 12 oz. 5 26.2
XC17−036−230−02 70 7 lbs. 12 oz. 5 26.2
XC17−036−230−03 70 7 lbs. 12 oz. 5 26.2
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XC17−042−230−01 70 7 lbs. 14 oz. 5 26.2
XC17−042−230−02 70 7 lbs. 14 oz. 5 26.2
XC17−042−230−03 70 7 lbs. 14 oz. 5 26.2
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XC17−048−230−01 73 12 lbs. 12 oz. 5 26.2
XC17−048−230−02 73 12 lbs. 12 oz. 5 26.2
XC17−048−230−03 73 12 lbs. 12 oz. 5 26.2
