Lennox XC17 Series

Page 3
XC17
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XC17−060−230−01 73 13 lbs. 4 oz. 5 26.2
XC17−060−230−02 73 13 lbs. 4 oz. 5 26.2
XC17−060−230−03 73 12 lbs. 14 oz. 5 26.2
1
Tested according to AHRI Standard 270−2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
Electrical Data
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over−
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XC17−024−230−01 30 18.9 13.5 58.3 1/4 400 2.0
XC17−024−230−02 30 18.9 13.5 58.3 1/4 400 2.0
XC17−024−230−03 30 18.9 13.5 58.3 1/4 400 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over−
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XC17−030−230−01 30 18.0 12.8 64.0 1/4 450 2.0
XC17−030−230−02 30 18.0 12.8 64.0 1/4 450 2.0
XC17−030−230−03 30 18.0 12.8 64.0 1/4 450 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over−
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XC17−036−230−01 30 19.6 14.1 77.0 1/4 600 2.0
XC17−036−230−02 30 19.6 14.1 77.0 1/4 600 2.0
XC17−036−230−03 30 19.6 14.1 77.0 1/4 600 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over−
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XC17−042−230−01 40 24.4 17.9 107.0 1/4 600 2.0
XC17−042−230−02 40 24.4 17.9 107.0 1/4 600 2.0
XC17−042−230−03 40 24.4 17.9 107.0 1/4 600 2.0
208/230V−60 Hz−1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over−
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XC17−048−230−01 50 29.3 21.8 117.0 1/4 675 2.0
XC17−048−230−02 50 29.3 21.8 117.0 1/4 675 2.0
XC17−048−230−03 50 29.3 21.8 117.0 1/4 675 2.0
