Lenovo PHAB Plus Hardware Maintenance Manual
50
4. Detach the connector of the main FPC from the main board using a pair of
tweezers.
Figure 7-4. Detaching the connector of the main FPC on the main baord
5. Remove screws at the positions as shown in the figure below.
Figure 7-5. The screws on the main board
Part No. Screw (quantity) Color Torque
Phillips cross head screw, M1.4 × 2.38(6) Black N/A
