Locatingconnectors,controls,andindicatorsonthefrontofyour
computer
Figure6“Frontconnector,control,andindicatorlocations”onpage74showsthelocationsofthe
connectors,controls,andindicatorsonthefrontofyourcomputer.
Figure6.Frontconnector,control,andindicatorlocations
1Opticaldriveeject/closebutton5USB2.0connector(USBport2)
2Powerswitch6Microphoneconnector
3Harddiskdriveactivityindicator7Headphoneconnector
4Powerindicator
8USB2.0connector(USBport1)
