Locatingcomponents
Figure3“Componentlocations”onpage12showsthelocationsofthevariouscomponentsinyour
computer.Toremovethecomputercover,see“Removingthecomputercover”onpage38.
Figure3.Componentlocations
1Heatsinkandfanassembly
7Systemfanassembly
2Powersupplyassembly8Thermalsensor
3Memorymodules(2)
9Harddiskdrive
4Opticaldrive10PCIExpresscard(installedinsomemodels)
5FrontaudioandUSBassembly
11Heatsinkfanduct
6Frontbezel
12ThinkCentreE73UserGuide
