Lenovo ThinkCentre E73 - Locating Internal Drives

Locatinginternaldrives
Internaldrivesaredevicesthatyourcomputerusestoreadandstoredata.Youcanadddrivestoyour
computertoincreasestoragecapacityandenableyourcomputertoreadothertypesofmedia.Internal
drivesareinstalledinbays.Inthismanual,thebaysarereferredtoasbay1,bay2,andsoon.
Wheninstallingorreplacinganinternaldrive,itisimportanttonotethetypeandsizeofthedrivethatyou
caninstallorreplaceineachbayandcorrectlyconnectthecablestothedriveinstalled.Refertothe
appropriatesectionin“Installingorreplacinghardware”onpage37forinstructionsonhowtoinstallor
replaceinternaldrivesforyourcomputer.
Figure5“Drivebaylocations”onpage14
showsthelocationsofthedrivebays.
Figure5.Drivebaylocations
1Bay1-Secondaryharddiskdrivebay(withaSATAsolid-statedriveorahybridharddiskdriveinstalledin
somemodels)
2Bay2-Opticaldrivebay(withanopticaldriveinstalledinsomemodels)
3Bay3-Slimcardreaderdrivebay(withaslimcardreaderinstalledinsomemodels)
4Bay4-Harddiskdrivebay(witha2.5-inchor3.5-inchSATAharddiskdriveinstalled)
