Chapter7.Locations
Thischapterhelpsyoulocatethehardwarecomponentsonyourcomputer.
Locatingcomputercontrols,connectors,andindicators
Thistopichelpsyoulocatethecontrols,connectors,andindicatorsonyourcomputer.
Frontview
1
2
1
3
4
10
12
14
5
6
7
8
9
11
13
1 Microphones
2 Camera
3 Screen
4 Powerbutton
5 LenovoOneLinkconnector
6 acpowerconnector
7 Ethernetconnector
8 High-DefinitionMultimediaInterface(HDMI™)
connector
9 USB3.0connectors 10 Systemstatusindicator
11 Trackpad 12 Media-cardslot
13 TrackPoint
®
buttons 14 TrackPointpointingstick
