1140Speakerassembly
Foraccess,removetheseFRUsinorder:
•“1010LenovoOneLinkconnectorcover”onpage60
•“1020DIMMdoor”onpage61
•“1030Internalstoragedrive”onpage61
•“1040Memorymodule”onpage62
•“1050WirelessLANcard”onpage63
•“1060Coin-cellbattery”onpage64
•“1070Keyboard”onpage65
•“1080Keyboardbezelassembly”onpage66
•“1090Mediacardreader”onpage68
•“1100USB/audiocard”onpage69
•“1120Systemboardandthermalfanassembly”onpage70
•“1130Batterypack”onpage77
Removalstepsofthespeakerassembly
Removethespeakercablesasshown.
1
1
1
1
1
1
1
1
Removethescrewsthatsecurethespeakerassembly.
2
2
2
2
Chapter9.RemovingorreplacingaFRU79
