Lenovo ThinkPad P52s User Manual

Attention: Do not touch the contact edge of the wireless-WAN card. Otherwise the wireless-WAN card
might get damaged.
To replace the wireless-WAN card, do the following:
1. Disable the built-in battery. See “Disabling the built-in battery” on page 100.
2. Ensure that the computer is turned off and disconnected from ac power and all cables.
3. Close the computer display and turn the computer over.
4. Remove the removable battery. See “Replacing the removable battery” on page 100.
5. Remove the base cover assembly. See “Replacing the base cover assembly” on page 103.
6. Remove the wireless-WAN card by doing the following:
Note: A Mylar film might cover the wireless-WAN card. To access the wireless-WAN card, open the film
first.
a. Hold the cable connector with your fingers and gently disconnect each cable from the wireless-WAN
card
1 . Then remove the screw that secures the wireless-WAN card 2 . The card is released from the
secured position and pivots upward.
b. Carefully remove the wireless-WAN card out of the slot
3 .
116 T580 and P52s User Guide

Lenovo ThinkPad P52s Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Glass Fibre Reinforced Plastic (GFRP), Polyphenylene sulfide (PPS)
Country of origin	France
Bus type	OPI
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i7
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4 GHz
Configurable TDP-up frequency	2 GHz
Configurable TDP-down frequency	0.8 GHz
Discrete graphics card	Yes
On-board graphics card	-
Motherboard chipset	Intel SoC
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 16 GB
SSD interface	M.2, NVMe, PCI Express
Storage media	SSD
Optical drive type	No
Total storage capacity	512 GB
Color gamut	45 %
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trusted Platform Module (TPM) version	2.0
Intel TSX-NI version	0.00
CPU configuration (max)	1
Intel Identity Protection Technology version	1.00
Privacy type	Privacy shutter
Front camera HD type	HD
Keyboard layout	AZERTY
Keyboard language	French
Battery capacity	56 Wh
AC adapter power	65 W
Operating system architecture	64-bit
Sustainability certificates	ENERGY STAR, EPEAT Gold, GREENGUARD, RoHS
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2

Weight and Dimensions

Depth	252.8 mm
Width	365.8 mm
Height	20.2 mm
Weight	1950 g
