Chapter 6. Advanced configuration
This chapter provides information to help you further configure the computer:
Installing the Windows 10 operating system
In some situations, you might need to install a new operating system. This topic provides instructions on how
to install a Windows 10 operating system.
Before you start, print these instructions.
Attention: The process of installing a new operating system deletes all the data on your internal storage
drive, including the data that were stored in a hidden folder.
To install the Windows 10 operating system, do the following:
1. Ensure that you set the security chip to TPM 2.0. For more information, see “Setting the security chip”
on page 55.
2. For computer models that support the Intel Optane technology, start the ThinkPad Setup program and
select Config ➙ Storage ➙ Controller Mode. Ensure that RST mode is selected.
3. Connect the drive that contains the operating system installation program to the computer.
4. Start the ThinkPad Setup program. See “Using the ThinkPad Setup program” on page 63.
5. Select Startup ➙ Boot to display the Boot Priority Order submenu.
6. Select the drive that contains the operating system installation program, for example, USB HDD. Then
press Esc.
7. Select Restart and ensure that OS Optimized Defaults is enabled. Then press F10 to save the settings
and exit the ThinkPad Setup program.
8. Follow the on-screen instructions to install the device drivers and necessary programs. See “Installing
device drivers” on page 62.
9. After installing the device drivers, apply Windows Update to get the latest modules, for example the
security patches.
10. Depending on your preference, install Lenovo programs. For information about Lenovo programs, see
“Lenovo programs” on page 14.
Note: After installing the operating system, do not change the initial UEFI/Legacy Boot setting in the
ThinkPad Setup program. Otherwise, the operating system will not start correctly.
For computer models that support the Intel Optane technology, continue to enable the Intel Optane memory
by doing the following:
1. Go to
http://www.lenovo.com/support. Download and install the Intel Rapid Storage Technology (Intel
RST) Console with device driver on your computer.
2. Run the Intel RST Console with device driver.
3. Click Intel® Optane™ Memory and then follow the instructions on the screen to enable it.
When you install the Windows 10 operating system, you might need one of the following country or region
codes:
© Copyright Lenovo 2018 61

Lenovo ThinkPad P52s Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Glass Fibre Reinforced Plastic (GFRP), Polyphenylene sulfide (PPS)
Country of origin	France
Bus type	OPI
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i7
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4 GHz
Configurable TDP-up frequency	2 GHz
Configurable TDP-down frequency	0.8 GHz
Discrete graphics card	Yes
On-board graphics card	-
Motherboard chipset	Intel SoC
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 16 GB
SSD interface	M.2, NVMe, PCI Express
Storage media	SSD
Optical drive type	No
Total storage capacity	512 GB
Color gamut	45 %
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trusted Platform Module (TPM) version	2.0
Intel TSX-NI version	0.00
CPU configuration (max)	1
Intel Identity Protection Technology version	1.00
Privacy type	Privacy shutter
Front camera HD type	HD
Keyboard layout	AZERTY
Keyboard language	French
Battery capacity	56 Wh
AC adapter power	65 W
Operating system architecture	64-bit
Sustainability certificates	ENERGY STAR, EPEAT Gold, GREENGUARD, RoHS
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2

Weight and Dimensions

Depth	252.8 mm
Width	365.8 mm
Height	20.2 mm
Weight	1950 g
