Lenovo ThinkPad P52s User Manual

Touch gesture (touch models
only)
Description
Touch: Swipe in from the left edge.
Mouse action: Click the task-view icon
on the taskbar.
Function: View all your open windows in task view.
• Short swipe for full-screened app or when your computer is in the tablet
mode
Touch: Swipe downwards shortly from the top edge.
Mouse action: Move your pointer to the top edge of the screen.
Function: Show a hidden title bar.
• Long swipe when your computer is in the tablet mode
Touch: Swipe in from the top edge to the bottom edge.
Mouse action: From the top edge of the screen, click and hold, move the
pointer to the bottom of the screen, and then release.
Function: Close the current app.
Tips on using the multi-touch screen
• The multi-touch screen is a glass panel covered with a plastic film. Do not apply pressure or place any
metallic object on the screen, which might damage the touch panel or cause it to malfunction.
• Do not use fingernails, gloved fingers, or inanimate objects for input on the screen.
• Regularly calibrate the accuracy of the finger input to avoid a discrepancy.
Tips on cleaning the multi-touch screen
• Turn off the computer before cleaning the multi-touch screen.
• Use a dry, soft, and lint-free cloth or a piece of absorbent cotton to remove fingerprints or dust from the
multi-touch screen. Do not apply solvents to the cloth.
• Gently wipe the screen using a top-down motion. Do not apply any pressure on the screen.
Using the special keys
Your computer has several special keys to help you work more easily and effectively.
20 T580 and P52s User Guide

Lenovo ThinkPad P52s Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Glass Fibre Reinforced Plastic (GFRP), Polyphenylene sulfide (PPS)
Country of origin	France
Bus type	OPI
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i7
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4 GHz
Configurable TDP-up frequency	2 GHz
Configurable TDP-down frequency	0.8 GHz
Discrete graphics card	Yes
On-board graphics card	-
Motherboard chipset	Intel SoC
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 16 GB
SSD interface	M.2, NVMe, PCI Express
Storage media	SSD
Optical drive type	No
Total storage capacity	512 GB
Color gamut	45 %
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trusted Platform Module (TPM) version	2.0
Intel TSX-NI version	0.00
CPU configuration (max)	1
Intel Identity Protection Technology version	1.00
Privacy type	Privacy shutter
Front camera HD type	HD
Keyboard layout	AZERTY
Keyboard language	French
Battery capacity	56 Wh
AC adapter power	65 W
Operating system architecture	64-bit
Sustainability certificates	ENERGY STAR, EPEAT Gold, GREENGUARD, RoHS
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2

Weight and Dimensions

Depth	252.8 mm
Width	365.8 mm
Height	20.2 mm
Weight	1950 g
