Liquid crystal display (LCD) notice
CAUTION:
The liquid crystal display (LCD) is made of glass, and rough handling or dropping the computer can
cause the LCD to break. If the LCD breaks and the internal fluid gets into your eyes or on your hands,
immediately wash the affected areas with water for at least 15 minutes; if any symptoms are present
after washing, get medical care.
Note: For products with mercury-containing fluorescent lamps (for example, non-LED), the fluorescent lamp
in the liquid crystal display (LCD) contains mercury; dispose of according to local, state, or federal laws.
Using headphones or earphones
CAUTION:
Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of
the equalizer to maximum increases the earphone and headphone output voltage and the sound
pressure level. Therefore, to protect your hearing, adjust the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time at high volume can be dangerous if the
output of the headphone or earphone connectors do not comply with specifications of EN 50332-2. The
headphone output connector of your computer complies with EN 50332-2 Sub clause 7. This specification
limits the computer’s maximum wide band true RMS output voltage to 150 mV. To help protect against
hearing loss, ensure that the headphones or earphones you use also comply with EN 50332-2 (Clause 7
limits) for a wide band characteristic voltage of 75 mV. Using headphones that do not comply with EN 50332-
2 can be dangerous due to excessive sound pressure levels.
If your Lenovo computer came with headphones or earphones in the package, as a set, the combination of
the headphones or earphones and the computer already complies with the specifications of EN 50332-1. If
different headphones or earphones are used, ensure that they comply with EN 50332-1 (Clause 6.5
Limitation Values). Using headphones that do not comply with EN 50332-1 can be dangerous due to
excessive sound pressure levels.
Choking hazard notice
CHOKING HAZARD Product contains small parts.
Keep away from children under three years.
Plastic bag notice
DANGER
Plastic bags can be dangerous. Keep plastic bags away from babies and children to avoid danger of
suffocation.
© Copyright Lenovo 2018 xv

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lenovo ThinkPad P52s and is the answer not in the manual?

Lenovo ThinkPad P52s Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack
Housing materialGlass Fibre Reinforced Plastic (GFRP), Polyphenylene sulfide (PPS)
Country of originFrance
Bus typeOPI
Processor cache8 MB
Processor cores4
Processor familyIntel® Core™ i7
Configurable TDP-up25 W
Processor frequency1.8 GHz
Configurable TDP-down10 W
Processor manufacturerIntel
Processor boost frequency4 GHz
Configurable TDP-up frequency2 GHz
Configurable TDP-down frequency0.8 GHz
Discrete graphics cardYes
On-board graphics card-
Motherboard chipsetIntel SoC
Internal memory32 GB
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)2 x 16 GB
SSD interfaceM.2, NVMe, PCI Express
Storage mediaSSD
Optical drive typeNo
Total storage capacity512 GB
Color gamut45 %
Display diagonal15.6 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness250 cd/m²
Bluetooth version4.1
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Trusted Platform Module (TPM) version2.0
Intel TSX-NI version0.00
CPU configuration (max)1
Intel Identity Protection Technology version1.00
Privacy typePrivacy shutter
Front camera HD typeHD
Keyboard layoutAZERTY
Keyboard languageFrench
Battery capacity56 Wh
AC adapter power65 W
Operating system architecture64-bit
Sustainability certificatesENERGY STAR, EPEAT Gold, GREENGUARD, RoHS
HDMI version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Weight and Dimensions IconWeight and Dimensions
Depth252.8 mm
Width365.8 mm
Height20.2 mm
Weight1950 g
