Lenovo ThinkPad P52s User Manual

• USB 3.1 connector Gen 1
Security features
• Face authentication (available on models with the infrared camera)
• Conventional camera with camera shutter (available on some models)
• Fingerprint reader (available on some models)
• Password
• Security-lock slot
• Trusted Platform Module (TPM)
Wireless features
• Bluetooth
• NFC (available on some models)
• Wireless LAN
• Wireless WAN (available on some models)
• Global Positioning System (GPS) satellite receiver (available on models with wireless WAN)
Others
• Conventional camera or infrared camera (available on some models)
• Microphones
Computer specifications
Size
• Width: 365.8 mm (14.4 inches)
• Depth: 252.8 mm (9.95 inches)
• Thickness: 19.95 mm (0.79 inches) to 20.2 mm (0.8 inches)
Maximum heat output (depending on the model)
• 45 W (154 Btu/hr)
• 65 W (222 Btu/hr)
Power source (ac power adapter)
• Sine-wave input at 50 Hz to 60 Hz
• Input rating of the ac power adapter: 100 V to 240 V ac, 50 Hz to 60 Hz
Operating environment
Maximum altitude (without pressurization)
• 3048 m (10 000 ft)
Temperature
• At altitudes up to 2438 m (8000 ft)
– Operating: 5°C to 35°C (41°F to 95°F)
Chapter 1. Product overview 13

Lenovo ThinkPad P52s Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Glass Fibre Reinforced Plastic (GFRP), Polyphenylene sulfide (PPS)
Country of origin	France
Bus type	OPI
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i7
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4 GHz
Configurable TDP-up frequency	2 GHz
Configurable TDP-down frequency	0.8 GHz
Discrete graphics card	Yes
On-board graphics card	-
Motherboard chipset	Intel SoC
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 16 GB
SSD interface	M.2, NVMe, PCI Express
Storage media	SSD
Optical drive type	No
Total storage capacity	512 GB
Color gamut	45 %
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trusted Platform Module (TPM) version	2.0
Intel TSX-NI version	0.00
CPU configuration (max)	1
Intel Identity Protection Technology version	1.00
Privacy type	Privacy shutter
Front camera HD type	HD
Keyboard layout	AZERTY
Keyboard language	French
Battery capacity	56 Wh
AC adapter power	65 W
Operating system architecture	64-bit
Sustainability certificates	ENERGY STAR, EPEAT Gold, GREENGUARD, RoHS
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2

Weight and Dimensions

Depth	252.8 mm
Width	365.8 mm
Height	20.2 mm
Weight	1950 g
