8.IfyouareinstructedtoreturntheoldEthernetcard,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage182.
InstallingorremovingtheThinkServerRAID300UpgradeKeyfor
AdvancedRAID
ThistopicprovidesinstructionsonhowtoinstallorremovetheThinkServerRAID300UpgradeKeyfor
AdvancedRAID(hereinafterreferredtoastheTR300Key).
TheTR300KeyexpandsthecapabilityofthesystemboardbyactivatingRAID5fortheThinkServerRAID
300(alsoknownasonboardSASsoftwareRAID).YoucanpurchaseaTR300KeyfromLenovo.
InstallingtheTR300Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage81.
ThistopicprovidesinstructionsonhowtoinstalltheTR300Key.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeTR300Keyandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheTR300Key,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.
3.Removetheservercover.See“Removingtheservercover”onpage83.
4.LocatetheiButtonsocketonthesystemboard.See“Systemboardcomponents”onpage48.Ifthereis
anyPCIExpresscardinstalledontherisercardassembly1,itmightblockyouraccesstotheiButton
socketonthesystemboard.Inthiscase,youneedtoremovethecoolingshroudandthencarefullylift
therisercardassembly1upsothatyoucanaccesstheiButtonsocket.Youdonotneedtodisconnect
anycablesfromtherisercardassembly1orcompletelyremovetherisercardassembly1.
5.Touchthestatic-protectivepackagethatcontainstheTR300Keytoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheTR300Keyoutofthepackage.
Chapter6.Installing,removing,orreplacinghardware119
