connectthemini-SASconnectorontheotherendofthecabletothemini-SASports0-3onthe
backplane.
2.Ifyourserverhasmorethanfourharddiskdrivesinstalled,forharddiskdrive4toharddiskdrive7,use
anothermini-SAStomini-SASsignalcableandconnectthemini-SASconnectorononeendofthe
cabletotheSASconnector4-7onthesystemboard.Then,connectthemini-SASconnectoronthe
otherendofthecabletothemini-SASports4-7onthebackplane.
Refertothefollowingtopicsforinformationabouttheconnectorlocationsandthepowercableconnections:
•“Hot-swapharddiskdrivebackplane”onpage39
•“Systemboardcomponents”onpage48
Systemboardcomponents
Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.
Figure37.Systemboardcomponents
1Frontpanelconnector
16ThinkServerManagementModule
2InternalUSBconnector1
17Risercardassembly1slot
3InternalUSBconnector2
18Risercardassembly2slot
4Diagnosticmoduleconnector19Redundantpowersupplyconnector1
5FrontVGAconnector
20Redundantpowersupplyconnector2
6SATAconnector0
21Backplanepowerconnector1
48ThinkServerRD430HardwareMaintenanceManual
