1SystemfanerrorLEDs
WhenasystemfanerrorLEDislitinamber,itindicatesthatthecorrespondingsystemfanisoperatingslowly
orhasfailed.Thefollowingillustrationshowsthesystemfansandtheirnumbers.
Notes:
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustration.
•Yourserverhasfoursystemfans.Thecallout3andcallout6indicatedummysystemfans.
Figure14.Systemfans
Chapter3.Productoverview25
