10.Reinstallallthehot-swapharddiskdrivesanddummytrays(ifany)intherearbackplane/cagekit.See
“Installingorreplacingahot-swapharddiskdrive”onpage123
.
11.Refertoyournotetoconnectthecablestothenewbackplane.
12.Ifyouareinstructedtoreturntheoldbackplane,followallpackaginginstructionsanduseanypackaging
materialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage152
.
ReplacingtheAnyRAIDadapter
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage59.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththenewAnyRAIDadapterandfollowthoseinstructionsin
additiontotheinstructionsinthistopic.
•Dependingonthemodel,yourAnyRAIDadaptermightlookdifferentfromtheillustrationsinthistopic.
ToreplacetheAnyRAIDadapter,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage61.
3.Removetheservercover.See“Removingtheservercover”onpage61.
4.LocatetheAnyRAIDadapter.See“Servercomponents”onpage25.
Chapter6.Replacinghardware103
