12.Closethemicroprocessorretainer.Then,closethesmallhandle1firstandthenclosethesmallhandle
2tolocktheretainerintopositionandsecurethenewmicroprocessorinthesocket.
Note:Therearetwomarksonthemicroprocessorretainer.Openthesmallhandlemarkedwith
firstandthenopentheothersmallhandlemarkedwith.Alwaysfollowthecorrectsequencewhen
youopenthesmallhandles.
Figure84.Securingthemicroprocessorinthesocket
13.Installthenewheatsinkthatcomeswiththemicroprocessoroptionkit.See“Installingorreplacinga
heatsink”onpage108
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage152
.
Replacingthemicroprocessor
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage59.
CAUTION:
Theheatsinkandmicroprocessormightbeveryhot.Turnofftheserverandwaitseveralminutesto
lettheservercoolbeforeremovingtheservercover.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Chapter6.Replacinghardware115
