10.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches
1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner4ofthemicroprocessorsocket.
Figure82.Installingthemicroprocessor
11.Removetheplasticmicroprocessorsocketcover.Storethemicroprocessorsocketcoverincasethat
youlaterremovethemicroprocessorandneedthesocketcovertoprotectthepinsonthesocket.
Note:Donotremovethesocketcoveruntilyouinstallamicroprocessorintothesocket.Ifyouremove
themicroprocessor,installthesocketcoveroranewmicroprocessorimmediately.
Figure83.Removingthemicroprocessorsocketcover
114ThinkServerRD550UserGuideandHardwareMaintenanceManual
