MT-M XXXX- XXX
S/N XXXXXXX
Figure2.Labelonservermodelswith2.5-inch-drivebays
Frontviewoftheserver
Thefrontviewoftheservervariesbymodel.Theillustrationsinthistopicshowtheserverfrontviews
basedonthesupportedinternaldrives:
•“Frontviewofservermodelswith3.5-inchdrives”onpage17
•“Frontviewofservermodelswith2.5-inchdrives”onpage18
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Frontviewofservermodelswith3.5-inchdrives
Figure3.Frontviewofservermodelswith3.5-inchdrives
1Frontpanel
2Slimopticaldrive(availableonsomemodels)
3Pull-outinformationcard
4Rackhandle(right)
53.5-inch-drivebays(0-3)6Rackhandle(left)
1Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage19.
Chapter3.Productoverview17
