Backplanefortwelve2.5-inchdrives
Thefollowingillustrationsshowtheslotsandconnectorsonthebackplaneforuptotwelve2.5-inchdrives.
Figure21.Frontviewofthebackplanefor2.5-inchdrives
Figure22.Rearviewofthebackplanefor2.5-inchdrives
0-11:Slot0-slot11
Usedtoconnect2.5-inchdrives.
12PCIesignalconnectors
UsedtoconnectthesignalcableforthePCIeinterposercard.
1310-pinpowerconnector
Usedtoconnecttothefront-backplanepowerconnectoronthesystemboardtoprovidepowertothe
backplane.
14AnyRAIDadapterslot(2)
UsedtoconnecttoanAnyRAIDadapter.
Chapter3.Productoverview35
