encryptionkeys,anddigitalcertificatestohelpprovidesecuritysolutionsandprotecttheserver.Youcan
purchaseaTPMoptionfromLenovo.
InstallingtheTPM
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage59.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeTPMandfollowthoseinstructionsinadditiontothe
instructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheTPM,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage61.
3.Removetheservercover.See“Removingtheservercover”onpage61.
4.Removetherisercardassembly1and2ifneeded.See“Replacingtherisercardassembly”on
page143.
5.Touchthestatic-protectivepackagethatcontainstheTPMtoanyunpaintedsurfaceontheoutsideof
theserver.Then,taketheTPMoutofthepackage.
Note:CarefullyhandletheTPMbyitsedges.
6.LocatetheTPMconnectoronthesystemboardandtheninserttheTPMintotheTPMconnector
onthesystemboard.
Figure42.InstallingtheTPM
Whattodonext:
74ThinkServerRD550UserGuideandHardwareMaintenanceManual
