10.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches
1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner4ofthemicroprocessorsocket.
Figure77.Installingthemicroprocessor
11.Removetheplasticmicroprocessorsocketcover.Storethemicroprocessorsocketcoverintheevent
thatyoulaterremovethemicroprocessorandneedthesocketcovertoprotectthepinsonthesocket.
Note:Donotremovethesocketcoveruntilyouinstallamicroprocessorintothesocket.Ifyouremove
themicroprocessor,installthesocketcoveroranewmicroprocessorinthefirstplace.
Figure78.Removingthemicroprocessorsocketcover
122ThinkServerRD640UserGuideandHardwareMaintenanceManual
