24.Notetheorientationofthepowersupplycoolingshroudandinstallitintothechassisbyinsertingthe
twosmalltabs
1onthebottomoftheshroudintothecorrespondingholes2inthepowersupplycage.
ID
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
PSU
Mem
CPU
Figure156.Installingthepowersupplycoolingshroud
25.Installthesystemboardbatteryonthenewsystemboard.See“Replacingthesystemboardbattery”on
page174
.
26.IfyouhaveaTMMPremium,installtheTMMPremiumonthenewsystemboard.See“Installingthe
TMMPremium”onpage107
.
27.IfyouhaveaTPM,installtheTPMonthenewsystemboard.See“InstallingtheTPM”onpage110.
28.Installthetworisercardassembliesonthenewsystemboard.See“Replacingtherisercardassembly
1”onpage155
and“Replacingtherisercardassembly2”onpage157.
29.Notetheorientationofthesystemfancage.Aligntheleftandrightsidesofthesystemfancagewiththe
correspondingmountingpostsinthechassis.Then,pressthesystemfancagewiththeinstalledsystem
fansstraightdownintothechassisuntilthesystemfancageiscorrectlyseatedandthesystemfansare
correctlyconnectedtothesystemfanconnectorsonthesystemboard.
ID
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
PSU
Mem
CPU
Figure157.Installingthesystemfancagewithsystemfans
Chapter6.Installing,removing,orreplacinghardware183
