6.Gentlypressdownthesmallhandle1onthemicroprocessorsocketandthenpullthehandleslightly
outwardtoreleaseitfromthesecuredposition.Then,pivotthehandleupwardtothefullyopenposition.
Then,gentlyopentheretainer
2toaccessthemicroprocessor3.
Figure71.Accessingthemicroprocessor
7.Ensurethatthesmallhandleandthemicroprocessorretainerareinthefullyopenposition.Touchonly
theedgesofthemicroprocessorandcarefullyliftitstraightupandoutofthemicroprocessorsocket.
Placetheoldmicroprocessoronastatic-protectivesurface.
Notes:
•Donottouchthegoldcontactsonthebottomofthemicroprocessor.
•Donotdropanythingontothemicroprocessorsocketwhileitisexposed.Thesocketpinsmustbe
keptascleanaspossible.
Figure72.Removingthemicroprocessor
8.Touchthestatic-protectivepackagethatcontainsthenewmicroprocessortoanyunpaintedsurfaceon
theoutsideoftheserver.Then,removethenewmicroprocessorfromthepackage.
98ThinkServerRS140UserGuideandHardwareMaintenanceManual
