Systemboardcomponents
Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.
Figure24.Systemboardcomponents
14-pinpowerconnector2DIMM1
3DIMM24DIMM3
5DIMM46Thermalsensorconnector
7IDLEDpowerconnector
8System-error-LED-cableconnector
9Systemfan3connector104-pinpowerconnectors(2)
1114-pinpowerconnector
12SATAconnector3
13SATAconnector014SATAconnector4
15SATAconnector116SATAconnector2
17Systemfan2connector
18Frontpanelconnector
19Hard-disk-drive-LEDconnector
20InternalUSB2.0connector
21ClearCMOS(ComplementaryMetalOxide
Semiconductor)/Recoveryjumper
22ManageabilityEngine(ME)disablejumper
23TrustedCryptographyModule(TCM)connector
24Risercardassemblyslot
25Systemfan1connector26Coin-cellbattery
14-pinpowerconnector
Usedtoconnecttheauxiliarypowerconnectorofthepowersupply.
32ThinkServerRS140UserGuideandHardwareMaintenanceManual
