2345Memoryslots
Therearefourmemoryslotsonthesystemboard.Fordetailedinformation,see“Memorymoduleinstallation
rules”onpage59.
6Thermalsensorconnector
Usedtoconnectthethermalsensorcable.
7IDLEDpowerconnector
UsedtoprovidepowertotheIDLEDonthefrontpanel.
8System-error-LED-cableconnector
UsedtoconnecttheSystem-error-LEDcable.
91725Systemfanconnectors
Therearethreesystemfansinstalledinyourserver.Eachsystemfanconnectorisusedtoconnecta
correspondingsystemfan.
104-pinpowerconnectors(2)
Usedtoprovidepowertoyourharddiskdrives.
1114-pinpowerconnector
Usedtoconnectthepowerconnectorofthepowersupplytoprovidemainpowertoyourserver.
12131516SATAconnectors0-3
UsedtoconnectSATAsignalcablesfortheharddiskdrives.
14SATAconnector4
Usedtoconnectthesignalcableoftheslimopticaldriveifyourserverhasaslimopticaldriveinstalled.
18Frontpanelconnector
Usedtoconnectthefrontpanelcable.
19Hard-disk-drive-LEDconnector
Usedtoconnectthehard-disk-drive-LEDcable.
20InternalUSB2.0connector
UsedtoconnectthetwoUSBconnectorsonthefrontpanel.
21ClearCMOS(ComplementaryMetalOxideSemiconductor)/Recoveryjumper
UsedtoclearCMOSandturntheBIOSsettingsintothefactorydefaultsettings.
Chapter3.Productoverview33
