3.Dothefollowingtoconnecttheslimopticaldrive:
a.1:ConnectoneendoftheavailableSATAcabletotheSATA4connectoronthesystemboard.
b.2:ConnecttheotherendoftheSATAcabletotherearoftheslimopticaldrive.
c.3:Connecttheslim-optical-drivepowerconnectorofacomboSAScabletothepowerconnector
attherearoftheslimopticaldrive.
Formoreinformation,see“Systemboardcomponents”onpage32.
Note:EnsurethattheSATAcableandthepowercablefortheslimopticaldriveareroutedunderthe
powersupplycableandthecomboSASpowercable.
Figure23.Connectingtheslimopticaldrive
4.Routethecablesusingthecabletiesinthechassis.See“Reinstallingtheservercoverandreconnecting
cables”onpage106.
Chapter3.Productoverview31
