Componentsofservermodelswithtwo3.5-inchhard-disk-drivebays
1
6
8
4
3
2
5
7
17
9
13
10
11
12
14
15
18
16
Figure9.Componentsofservermodelswithtwo3.5-inchhard-disk-drivebays
1Servercover
2Risercardassembly
3Ethernetcard4Fanduct
5Systemfan1
6Powersupplyassembly
7Systemfan3
8Heatsink
9Rackhandle(right)
10Microprocessor
11Slim-optical-drivebracket12Slimopticaldrive
