9.Touchthestatic-protectivepackagethatcontainsthenewrisercardassemblytoanyunpaintedsurface
ontheoutsideoftheserver.Then,removethenewrisercardassemblyfromthepackage.
10.InstalltheEthernetcardonthenewrisercardassembly.See“ReplacingtheEthernetcard”onpage77.
11.ReconnecttheEthernet-card/ID-LEDcabletotheEthernetcard.RoutetheEthernet-card/ID-LEDcable
fromthebottomoftherisercardassemblytoavoidinterferencewithreinstallingtheservercover.
12.Positionthenewrisercardassemblyonthechassisandalignitwiththerisercardassemblysloton
thesystemboard.Alignthetwoscrewholesinthenewrisercardassemblywiththecorresponding
holesinthechassis.Then,carefullypressthenewrisercardassemblystraightdownintotheslot
untilthenewrisercardassemblyisfullyseated.
Figure48.Installingthenewrisercardassembly
13.ReinstallthePCIExpresscardonthenewrisercardassembly.See“InstallingtheRAIDcard”on
page62.
14.Ifyouareinstructedtoreturntheoldrisercardassembly,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage106
.
ReplacingtheEthernetcard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•TheEthernetcardissensitivetoESD.Ensurethatyoureadandunderstand“Handlingstatic-sensitive
devices”onpage54
firstandcarefullyperformtheoperation.
•Dependingonthespecifictype,theEthernetcardmightlookdifferentfromtheillustrationsinthistopic.
•UseanydocumentationthatcomeswiththeEthernetcardandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
Chapter6.Installing,removing,orreplacinghardware77
