Thefollowingillustrationshowsthefrontviewoftheserver.
Figure2.Frontviewoftheserver
1Opticaldriveeject/closebutton
4Powerbutton
2HarddiskdriveactivityLED
5USB3.0connectors(2)
3Power-onLED
Rearviewoftheserver
Thistopicprovidesinformationtohelpyoulocatetheconnectorsandcomponentsontherearofyourserver.
Figure3“Rearconnectorlocations”onpage12
showsthelocationsoftheconnectorsontherearof
yourserver.Someconnectorsontherearofyourserverarecolor-codedtohelpyoudeterminewhere
toconnectthecablesonyourserver.
Chapter3.Productoverview11
