Lenovo ThinkServer TS140 - Installing or Replacing the Secondary Hard Disk Drive

9.ConnectoneendofthesignalcabletotheharddiskdriveandtheotherendtoanavailableSATA
connectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage13.Then,locatean
availablefive-wirepowerconnectorandconnectittotheharddiskdrive.
Figure19.ConnectingaSATAharddiskdrive
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage83.
Installingorreplacingthesecondaryharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage35.
Thistopicprovidesinstructionsonhowtoinstallorreplacethesecondaryharddiskdrive.
Note:Fora2.5-inchharddiskdriveorsolid-statedrive,installthedriveintoa3.5-inchto2.5-inchdrive
adapterfirst.See“Installingthe2.5-inchsolid-statedriveorharddiskdrive”onpage45
.
Toinstallorreplacethesecondaryharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage37.
3.Locatethesecondaryharddiskdrive.See“Locatingpartsonthesystemboard”onpage13and
“Internaldrives”onpage14.
4.Ifyouarereplacingthesecondaryharddiskdrive,disconnectthesignalcableandthepowercable
fromtheharddiskdrive.
Chapter6.Installing,removing,orreplacinghardware49
