Figure43.Removingtheharddiskdrivefromthecage
10.Toinstallanewslimopticaldriveandanewfourthharddiskdrive,see“Installingtheslimoptical
driveandthefourthharddiskdrive”onpage56.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage83.
InstallingorreplacingaPCIcard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage35.
ThissectionprovidesinstructionsonhowtoinstallorreplaceaPCIcard.
YourserverhasonestandardPCIcardslot,onePCIExpressx1cardslot,onePCIExpressx4cardslot,and
onePCIExpressx16cardslot.
ToinstallorreplaceaPCIcard,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage37.
