8.Toinstallanewtertiaryharddiskdrive,see“Installingthetertiaryharddiskdrive”onpage51.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage83.
Installingorremovingtheslimopticaldriveandthefourthharddiskdrive
Thissectionprovidesinstructionsonhowtoinstallorremovetheslimopticaldriveandthefourthhard
diskdrive.
Note:Fora2.5-inchharddiskdriveorsolid-statedrive,installthedriveintoa3.5-inchto2.5-inchdrive
adapterfirst.See“Installingthe2.5-inchsolid-statedriveorharddiskdrive”onpage45.
Installingtheslimopticaldriveandthefourthharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage35.
Youcaninstallaslimopticaldriveandafourthharddiskdriveintotheopticaldrivebayofyourserver.
Thistopicprovidesinstructionsonhowtoinstalltheslimopticaldriveandthefourthharddiskdriveintothe
opticaldrivebay.
Toinstalltheslimopticaldriveandthefourthharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage37.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage38.
4.Installtheslimopticaldriveconversionboardintothecagefortheslimopticaldriveandthefourthhard
diskdrive.Then,installthetwoscrewstosecuretheslimopticaldriveconversionboard.
Figure31.Installingtheslimopticaldriveconversionboard
