8.Slidethenewharddiskdriveintotheharddiskdrivecageuntilitsnapsintoposition.
Figure22.Installingthesecondaryharddiskdrive
9.ConnectoneendofthesignalcabletotheharddiskdriveandtheotherendtoanavailableSATA
connectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage13.Then,locatean
availablefive-wirepowerconnectorandconnectittotheharddiskdrive.
Figure23.ConnectingaSATAharddiskdrive
Installingorremovingthetertiaryharddiskdrive
Thistopicprovidesinstructionsonhowtoinstallorremovethetertiaryharddiskdrive.
Note:Fora2.5-inchharddiskdriveorsolid-statedrive,installthedriveintoa3.5-inchto2.5-inchdrive
adapterfirst.See“Installingthe2.5-inchsolid-statedriveorharddiskdrive”onpage45
.
Installingthetertiaryharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage35.
Youcaninstallatertiary3.5-inchharddiskdriveintothesecondaryopticaldrivebayofyourserver.
Chapter6.Installing,removing,orreplacinghardware51
