•Themaximumsystemmemoryis32GB(one8GBmemorymoduleinstalledineachofthefourmemory
slots).
Formoreinformationaboutthememorymodulesinyourspecificservermodel,usetheSetupUtility
program.See“ViewinginformationintheSetupUtilityprogram”onpage19
.
ForalistofsupportedThinkServermemorymoduleoptions,goto:http://www.lenovo.com/thinkserver
Thefollowingillustrationhelpsyoutolocatethememoryslotsonthesystemboard.
Figure10.Memoryslotsonthesystemboard
1Memoryslot(DIMM1)3Memoryslot(DIMM3)
2Memoryslot(DIMM2)4Memoryslot(DIMM4)
Thefollowingtableexplainsthememorymoduleinstallationrulesforyourserver.The“X”markindicatesthe
memoryslotsintowhichthememorymodulesshouldbeinstalledindifferentsituations.
Note:Theinstalledmemorymodulesmustbethesametypewiththesamevoltageandfrequency.
Table1.Memorymoduleinstallationrules
DIMMDIMM1DIMM2DIMM3DIMM4
OneDIMM
X
TwoDIMMsXX
ThreeDIMMsXXX
FourDIMMsXXXX
42ThinkServerTS140UserGuide
