1.Installthe2.5-inchdriveintothe3.5-inchto2.5-inchdriveadapter.Then,installthefourscrewsto
securethe2.5-inchdrivetothedriveadapter.
Figure14.Installingthe2.5-inchdriveintothedriveadapter
2.Toinstallthe2.5-inchdrivewiththedriveadapterintothe3.5-inchhard-disk-drivebracket,flexthe
bracketandalignpin1,pin2,pin3,andpin4onthebracketwiththecorrespondingholesin
thedriveadapter.
Figure15.Installingthe2.5-inchdrivewiththedriveadapterintothehard-disk-drivebracket
3.Connectthesignalcableandthepowercabletothe2.5-inchdrive.
46ThinkServerTS140UserGuide
