9.Connectthecableofthefanforthetertiaryharddiskdrivetooneoftheavailableconnectors1ofthe
fanpowerconvertercable.Then,connecttheconnector2totheharddiskdrivefanconnectoronthe
systemboard.See“Locatingpartsonthesystemboard”onpage13.
Figure28.Connectingthecableofthefanforthetertiaryharddiskdrive
10.Removetheplasticpanelthatprotectsthesecondaryopticaldrivebayfromthefrontbezel.
11.Reinstallthefrontbezel.See“Removingandreinstallingthefrontbezel”onpage38.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage83.
Removingthetertiaryharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage35.
Thistopicprovidesinstructionsonhowtoremovethetertiary3.5-inchharddiskdrive.
Toremovethetertiary3.5-inchharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage37.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage38.
4.Disconnectthesignalcableandthepowercablefromtherearofthetertiaryharddiskdrive.
5.Disconnectthecableofthefanforthetertiaryharddiskdrivefromthefanpowerconvertercable.
