5.Slidethenewopticaldrivewiththeopticaldriveretainer1installedintothedrivebayfromthefrontof
theserveruntiltheopticaldrivesnapsintoposition.
Figure50.Installingtheopticaldrive
6.Reinstallthefrontbezel.See“Removingandreinstallingthefrontbezel”onpage38.
7.ConnectoneendofthesignalcabletotheopticaldriveandtheotherendtoanavailableSATA
connectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage13
.Then,locatean
availablefive-wirepowerconnectorandconnectittotheSATAdrive.
Figure51.ConnectingaSATAopticaldrive
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage83.
InstallingorreplacinganinternalRDXdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage35.
Chapter6.Installing,removing,orreplacinghardware67
