The following table lists drive types and internal drive bay configurations that are supported by the internal
RAID controller.
Table 8. Storage controllers, drive types, and internal drive bays
Storage controller Drive type 4x 3.5-inch + 1x 2.5-inch non-hot-swap drive bays
RAID 121i NL SATA HDD Yes
SATA SSD Yes
RAID 520i NL SATA HDD Yes
SATA SSD Yes
Drives for internal storage
The TS150 server supports the internal drive options listed in the following table.
Table 9. Internal drive options
Description Part number
Maximum
supported
3.5-inch non-hot-swap HDDs - SATA 6 Gbps
ThinkServer 3.5" 1TB 7.2K SATA 6Gbps Hard Drive 4XB0G88755 4
ThinkServer 3.5" 2TB 7.2K SATA 6Gbps Hard Drive 4XB0G88756 4
3.5-inch non-hot-swap HDDs - NL SATA 6 Gbps
ThinkServer TS150 3.5" 500GB 7.2K Enterprise SATA 6Gbps HDD 4XB0G88758 4
ThinkServer TS150 3.5" 1TB 7.2K Enterprise SATA 6Gbps HDD 4XB0G88760 4
ThinkServer TS150 3.5" 2TB 7.2K Enterprise SATA 6Gbps HDD 4XB0G88764 4
ThinkServer TS150 3.5" 4TB 7.2K Enterprise SATA 6Gbps HDD 4XB0G88796 4
ThinkServer TS150 3.5" 5TB 7.2K Enterprise SATA 6Gbps HDD 4XB0G88797 4
ThinkServer TS150 3.5" 6TB 7.2K Enterprise SATA 6Gbps HDD 4XB0G88798 4
2.5-inch non-hot-swap SSDs (2.5-in. SSDs in 3.5-in. drive trays) - PM863a Enterprise Entry SATA 6 Gbps
TS150 2.5" 240GB PM863a Enterprise Entry SATA 6Gbps SSD with 3.5" Tray 4XB0K12354 5
TS150 2.5" 480GB PM863a Enterprise Entry SATA 6Gbps SSD with 3.5" Tray 4XB0K12355 5
TS150 2.5" 960GB PM863a Enterprise Entry SATA 6Gbps SSD with 3.5" Tray 4XB0K12356 5
2.5-inch non-hot-swap SSDs (2.5-in. SSDs in 3.5-in. drive trays) - S3520 Entry SATA 6 Gbps
TS150 2.5" 240GB S3520 Entry SATA 6Gbps SSD with 3.5" Tray 4XB0K12328 5
TS150 2.5" 480GB S3520 Entry SATA 6Gbps SSD with 3.5" Tray 4XB0K12331 5
TS150 2.5" 960GB S3520 Entry SATA 6Gbps SSD with 3.5" Tray 4XB0K12334 5
SD cards
ThinkServer 8GB SD Card 4X70F28592 2
Optical drives
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 12
