Lenovo ThinkServer TS150 Product Guide

Optical drives
The TS150 server supports the optical drive options listed in the following table.
Table 10. Optical drive options
Description Part number
Maximum
supported
Half high optical drives
ThinkServer Half High SATA DVD-RW Optical Disk Drive 4XA0F28605 2
ThinkServer Half High SATA DVD-ROM Optical Disk Drive 4XA0F28606 2
Slim optical drives
ThinkServer Slim SATA DVD-RW Optical Disk Drive 4XA0F28607 2
ThinkServer Slim SATA DVD-ROM Optical Disk Drive 4XA0F28608 2
The SATA Optical Disk Drives support the following types of media: CD-R, CD-ROM, CD-RW, DVD-R, DVD-
R (dual-layer recording), DVD-RAM, DVD-RW, DVD+R, DVD+R (dual-layer recording), and DVD+RW.
Configuration notes:
A slim optical drive allows support for up to 4x 3.5-inch + 1x 2.5-inch internal drive bays in the server
without a second optical drive or an internal backup unit; or up to 3x 3.5-inch + 1x 2.5-inch internal
drive bays in the server with a second optical drive or an internal backup unit.
The 3.5" HDD to 5.25" Tray Convertor with Slim ODD Kit (4XF0G88936) is required to support a slim
optical drive.
A half high optical drive limits the maximum number of internal drive bays to 3x 3.5-inch + 1x 2.5-
inch in the server without a second optical drive or an internal backup unit; or to 2x 3.5-inch + 1x 2.5-
inch in the server with a second optical drive or an internal backup unit.
If two optical drives are used, an internal backup unit is not supported.
Internal backup units
The TS150 server supports the internal backup unit options listed in the following table.
Table 11. Internal backup unit options
Description Part number
Maximum
supported
Internal RDX backup unit (USB)
ThinkServer Internal RDX Tape Drive 4XF0F28769 1
Cartridges for RDX backup unit
ThinkServer 1TB SATA 3Gbps RDX Cartridge 4XB0F28660 1
ThinkServer 2TB SATA 3Gbps RDX Cartridge 4XB0G88711 1
Configuration note: If an internal backup unit is used, a maximum of one optical drive is supported.
I/O expansion
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 13

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
